mrgsim.ds: 'Apache' 'Arrow' Dataset-Backed Simulation Outputs for 'mrgsolve'

mrgsim.ds provides an Apache Arrow-backed simulation output object for mrgsolve, greatly reducing the memory footprint of large simulations and providing a high-performance pipeline for summarizing huge simulation outputs. The arrow-based simulation output objects in R claim ownership of their files on disk. Those files are automatically removed when the owning object goes out of scope and becomes subject to the R garbage collector. While "anonymous", parquet-formatted files hold the data in tempdir() as you are working in R, functions are provided to move this data to more permanent locations for later use.

Package-wide options

• mrgsim.ds.show.gc: print messages to the console when object files are removed prior to object cleanup.

Function listing

• Load models

  • mread_ds()

  • mcode_ds()

  • mread_cache_ds()

  • modlib_ds()

  • house_ds()

• Generate Apache Arrow dataset-backed outputs

  • mrgsim_ds()

  • as_mrgsim_ds()

• S3 Methods

  • head.mrgsimsds()

  • tail.mrgsimsds()

  • dim.mrgsimsds()

  • names.mrgsimsds()

• Move or rename files

  • rename_ds()

  • move_ds()

  • write_ds()

• Ownership

  • ownership()

  • check_ownership()

  • list_ownership()

  • take_ownership()

  • disown()

  • copy_ds()

• Work with lists of outputs

  • reduce_ds()

  • refresh_ds()

  • prune_ds()

• Manage tempdir

  • list_temp()

  • retain_temp()

  • purge_temp()

• Enter dplyr / arrow pipelines with

  • dplyr::mutate()

  • dplyr::select()

  • dplyr::filter()

  • dplyr::summarise()

  • dplyr::summarize()

  • dplyr::rename()

  • dplyr::arrange()

  • dplyr::group_by()

• Coerce to R objects

  • as.data.frame()

  • dplyr::as_tibble()

  • dplyr::collect()

  • as_arrow_ds()

  • arrow::as_arrow_table()

  • as_duckdb_ds()

See also

Useful links:

• https://github.com/kylebaron/mrgsim.ds

• https://kylebaron.github.io/mrgsim.ds/

• https://kylebaron.r-universe.dev/mrgsim.ds

• Report bugs at https://github.com/kylebaron/mrgsim.ds/issues

Author

Maintainer: Kyle T Baron kylebtwin@imap.cc (ORCID) [copyright holder]

Examples

mod <- house_ds(end = 32)

data <- evd_expand(amt = seq(100, 300, 10))

out <- mrgsim_ds(mod, data)

out
#> Model: housemodel
#> Dim  : 2,730 x 7
#> Files: 1 [129 Kb]
#> Owner: yes
#>     ID TIME       GUT     CENT     RESP       DV       CP
#> 1:   1 0.00   0.00000  0.00000 50.00000 0.000000 0.000000
#> 2:   1 0.00 100.00000  0.00000 50.00000 0.000000 0.000000
#> 3:   1 0.25  74.08182 25.74883 48.68223 1.287441 1.287441
#> 4:   1 0.50  54.88116 44.50417 46.18005 2.225208 2.225208
#> 5:   1 0.75  40.65697 58.08258 43.61333 2.904129 2.904129
#> 6:   1 1.00  30.11942 67.82976 41.37943 3.391488 3.391488
#> 7:   1 1.25  22.31302 74.74256 39.57649 3.737128 3.737128
#> 8:   1 1.50  16.52989 79.55944 38.18381 3.977972 3.977972

head(out)
#> # A tibble: 6 × 7
#>      ID  TIME   GUT  CENT  RESP    DV    CP
#>   <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl>
#> 1     1  0      0     0    50    0     0
#> 2     1  0    100     0    50    0     0
#> 3     1  0.25  74.1  25.7  48.7  1.29  1.29
#> 4     1  0.5   54.9  44.5  46.2  2.23  2.23
#> 5     1  0.75  40.7  58.1  43.6  2.90  2.90
#> 6     1  1     30.1  67.8  41.4  3.39  3.39

tail(out)
#> # A tibble: 6 × 7
#>      ID  TIME      GUT  CENT  RESP    DV    CP
#>   <dbl> <dbl>    <dbl> <dbl> <dbl> <dbl> <dbl>
#> 1    21  30.8 4.71e-14  67.3  37.2  3.36  3.36
#> 2    21  31   3.49e-14  66.4  37.3  3.32  3.32
#> 3    21  31.2 2.58e-14  65.6  37.4  3.28  3.28
#> 4    21  31.5 1.91e-14  64.8  37.5  3.24  3.24
#> 5    21  31.8 1.42e-14  64.0  37.6  3.20  3.20
#> 6    21  32   1.05e-14  63.2  37.8  3.16  3.16

plot(out, nid = 10)


list_temp()
#> 1 files [129 Kb]
#> - mrgsims-ds-1b911d4f2d4b.parquet

ownership()
#> > Objects: 5 | Files: 5 | Size: 162 Kb

if (FALSE) { # \dontrun{

rename_ds(out, "reg-100-300")

list_temp()

move_ds(out, "data/sim/regimens")
} # }
